Model Number:
mood ype gazebo
Dimensions:
Standard sizes: from 3 x 3 meters to 5 x 5 meters
Brand:
UNOSIDER
Country:
Italy
Finish:
Powder Coated
Material:
Aluminium

The Mood range expands to meet increasingly diversified needs with Mood Ype . The load-bearing structure, made entirely of 120 x 120 mm section aluminum profiles , has greater stability and strength, while the manually retractable cover can reach a Maximum surface area of ​​5 x 5 meters. Mood Ype allows you to create numerous new configurations and customizations: to the traditional side curtains and to the LED strip lighting system, there are in fact screen panels, vertical drop awnings and finally the possibility of inserting a perimeter gutter channel for collection. of rainwater. The perimeter gutter, considerably increasing the performance level of the product, transforms the pavilion into a perfect answer even for the most demanding Contract solutions.

Technical information:

  • pillar section 120 x 120 x 2 mm
  • beam section 120 x 120 x 2 mm
  • possibility of custom making up to a maximum of 500 x 500 cm
  • extruded aluminum profiles, UNI6060 primary alloy and stainless steel accessories
  • epoxy powder coating based on polyester resin, resistant to UV rays
  • possibility of customizing the painting (with reference to the RAL color chart) subject to approval by the technical office
  • manual retractable roof
  • runoff of rainwater guaranteed by the inclination of the fabric channels of the cover sheet
  • standard cover in STAM pvc, heat-sealed, waterproof, fireproof class 2 / UNI9177

Accessories:

  • Compact transparent polycarbonate protective roof to protect the roof in the collected position
  • dimmable LED strips integrated into the aluminum profiles of the sliding cover
  • side curtains in acrylic fabric with zip closure and fixing profiles to the columns
  • vertical roller blind in SOLTIS 96 fabric with manual or motorized winch complete with steel sliding cables
  • lateral shading screens in aluminum profiles available in the colors of the structure
  • ALSO AVAILABLE WITH EAVES
  • Can be made to measure
